IzyDisplay Developer Guide

Version: 2.0.0
Device Model: IZYDISPLAY
Display: 480x272 RGB LCD with Capacitive Touch

Table of Contents

1. Overview
2. First-Time Setup
3. Device Settings
4. API Reference
5. Widget Types
6. Styling Guide
7. Event System
8. Examples

Overview

IzyDisplay is a WiFi-enabled smart display that receives UI templates via HTTP and renders them. It features:

• 480x272 RGB LCD with capacitive touch
• WiFi connectivity (DHCP or Static IP)
• WebServer on port 80 with /ui endpoint
• Access token authentication
• Real-time UI updates via JSON templates
• Interactive widgets with event callbacks (onClick, onChange)
• QR code display support
• Template variables for dynamic content

First-Time Setup

Step 1: Power On the Device

On first boot, the device enters Setup Mode automatically (no WiFi configured).

Step 2: Connect to Setup WiFi

1. Look for WiFi network: IZYDISPLAY_<device_id>
   • Example: IZYDISPLAY_E89F6D123456
2. Connect to it (no password required)
3. Your phone/computer will show a captive portal

Step 3: Configure via Web Portal

The setup page will open automatically at http://192.168.4.1

Configuration Options:

Setup Portal Screenshots:

Complete setup form with all configuration options

Optional access token feature with checkbox to enable secure communication

Step 4: Save & Connect

1. Click "Save & Apply"
2. Device will reboot and connect to your WiFi
3. Check your router for the device's IP address

Save confirmation with reboot message

Finding Device IP:

• If DHCP: Check router's DHCP client list
• If Static: Use the IP you configured
• Serial monitor will print: WiFi IP: 192.168.1.xxx

Device Settings

Accessing Settings Screen

Long-press (3 seconds) on the app name at the top of the display.

Settings Information:

• Device ID (MAC address)
• Firmware Version
• WiFi SSID
• IP Address
• Gateway
• App Name

Available Actions:

• Demo button: Load demo screen
• Reset button: Factory reset (clears all config)
• Exit button: Return to main screen

API Reference

Base URL

http://<device_ip>

Replace <device_ip> with your device's IP address (e.g., 192.168.1.18).

Endpoints

1. Root Endpoint - Device Info

GET /

Response:

<h1>IzyDisplay Smart Screen</h1>
<p>Device ID: E89F6D123456</p>
<p>Version: 2.0.0</p>
<p>Status: Online</p>

2. UI Template Endpoint

POST /ui
Content-Type: application/json
X-Access-Token: <your_token>

Request Body:

{
  "template": {
    "template_id": "optional_id",
    "widgets": [ /* widget array */ ]
  },
  "data": {
    "key": "value"
  }
}

Important Notes:

• Template level: Use "template_id" (not "id") to identify the template
• Widget level: Use "id" for individual widgets
• Data updates: Without a valid template_id, data-only updates will fail with 400 "No active template"

Headers:

• Content-Type: application/json (required)
• X-Access-Token: <token> (optional) - Required only if secure communication is enabled on device. Must match configured token.

Response:

{
  "status": "success",
  "message": "Template loaded"
}

Error Responses:

{
  "status": "error",
  "message": "Invalid access token"
}

{
  "status": "error",
  "message": "Invalid JSON"
}

Widget Types

1. Label

Display text with styling.

{
  "type": "label",
  "id": "title",
  "text": "Hello World",
  "x": 10,
  "y": 10,
  "width": 460,
  "style": {
    "text_color": "#FFFFFF",
    "text_font": "MONTSERRAT_24",
    "text_align": "center"
  }
}

2. Button

Interactive button with click events.

{
  "type": "button",
  "id": "submit_btn",
  "text": "Submit",
  "x": 190,
  "y": 200,
  "width": 100,
  "height": 50,
  "style": {
    "bg_color": "#0EA5E9",
    "text_color": "#FFFFFF",
    "radius": 10
  },
  "onClick": {
    "target_url": "http://192.168.1.100/api/submit",
    "method": "POST",
    "params": {
      "action": "submit"
    }
  }
}

3. QR Code

Display QR codes for URLs, text, etc.

{
  "type": "qrcode",
  "id": "qr1",
  "text": "https://example.com",
  "size": 200,
  "x": 140,
  "y": 36,
  "style": {
    "bg_color": "#FFFFFF",
    "fg_color": "#000000"
  }
}

4. Slider

Adjustable slider with value change events.

{
  "type": "slider",
  "id": "brightness",
  "min": 0,
  "max": 100,
  "value": 50,
  "x": 50,
  "y": 100,
  "width": 380,
  "onChange": {
    "target_url": "http://192.168.1.100/api/brightness",
    "method": "POST",
    "params": {
      "value": "${self}"
    }
  }
}

Note: Slider onChange events trigger only when the user releases the slider (not during dragging) to avoid flooding the network with requests and maintain smooth UI performance.

5. Switch

On/off toggle switch.

{
  "type": "switch",
  "id": "power",
  "checked": true,
  "x": 200,
  "y": 150,
  "onChange": {
    "target_url": "http://192.168.1.100/api/power",
    "method": "POST",
    "params": {
      "state": "${self}"
    }
  }
}

6. Checkbox

Checkbox with label.

{
  "type": "checkbox",
  "id": "agree",
  "text": "I agree to terms",
  "checked": false,
  "x": 50,
  "y": 200
}

7. Image

Display PNG or GIF images from URL or base64.

Supported Formats:

• PNG (recommended)
• GIF (including animations)
• JPEG (detected but not yet supported - convert to PNG)

From URL:

{
  "type": "image",
  "id": "logo",
  "src": "https://example.com/logo.png",
  "x": 200,
  "y": 50,
  "width": 183,
  "height": 156
}

Base64 Image:

{
  "type": "image",
  "id": "logo_b64",
  "align": "center"
}

Note: Maximum image size is 512KB. Images are cached in PSRAM (up to 5 images).

8. Container (Panel)

Container for grouping widgets.

{
  "type": "obj",
  "id": "panel1",
  "x": 10,
  "y": 10,
  "width": 460,
  "height": 250,
  "scrollable": true,
  "scroll_dir": "vertical",
  "style": {
    "bg_color": "#1E293B",
    "radius": 10,
    "pad_all": 10
  },
  "widgets": [
    /* child widgets */
  ]
}

9. Spinner

Loading spinner animation.

{
  "type": "spinner",
  "id": "loader",
  "x": 220,
  "y": 116,
  "width": 40,
  "height": 40
}

10. Toast

Android-style temporary message that auto-dismisses after duration.

{
  "type": "toast",
  "text": "Operation successful!",
  "duration": 3000,
  "position": "bottom"
}

Properties:

• text (required): Message to display
• duration (optional): Auto-dismiss time in milliseconds (default: 3000)
• position (optional): "top", "center", or "bottom" (default: "bottom")

Note: Toasts float on top of all other widgets and automatically delete themselves after the specified duration.

Styling Guide

Common Style Properties

Available Fonts

Built-in fonts not listed (MONTSERRAT_14-60 available).

Color Formats

"#FFFFFF"         // Hex RGB
"#FFF"            // Short hex
{"r": 255, "g": 255, "b": 255}  // RGB object

Event System

onClick Event

Triggered when a widget is clicked (button, label, etc.).

{
  "type": "button",
  "id": "action_btn",
  "onClick": {
    "target_url": "http://192.168.1.100/api/action",
    "method": "POST",
    "params": {
      "action": "start",
      "timestamp": "${timestamp}"
    }
  }
}

onChange Event

Triggered when a widget value changes (slider, switch, checkbox).

{
  "type": "slider",
  "id": "volume",
  "onChange": {
    "target_url": "http://192.168.1.100/api/volume",
    "method": "POST",
    "params": {
      "level": "${self}",
      "device_id": "living_room"
    }
  }
}

Parameter Substitution

Example with Multiple Widget Values:

{
  "type": "button",
  "id": "submit",
  "onClick": {
    "target_url": "http://192.168.1.100/api/settings",
    "method": "POST",
    "params": {
      "brightness": "${brightness_slider}",
      "power": "${power_switch}",
      "mode": "manual"
    }
  }
}

Event Request Format

When an event is triggered, the device sends:

Request:

POST http://192.168.1.100/api/action
Content-Type: application/json

{
  "value": "75",
  "widget_id": "brightness_slider",
  "brightness": "75",
  "power": "true",
  "mode": "manual"
}

Examples

Example 1: Simple Welcome Screen

curl -X POST http://192.168.1.18/ui \
  -H "Content-Type: application/json" \
  -H "X-Access-Token: IZYDISPLAY@2026" \
  -d '{
    "template": {
      "template_id": "welcome",
      "widgets": [
        {
          "type": "label",
          "text": "Welcome to IzyDisplay",
          "x": 0,
          "y": 100,
          "width": 480,
          "style": {
            "text_color": "#38BDF8",
            "text_align": "center"
          }
        }
      ]
    }
  }'

Example 2: Interactive Brightness Control

curl -X POST http://192.168.1.18/ui \
  -H "Content-Type: application/json" \
  -H "X-Access-Token: IZYDISPLAY@2026" \
  -d '{
    "template": {
      "widgets": [
        {
          "type": "label",
          "id": "title",
          "text": "Brightness Control",
          "x": 0,
          "y": 20,
          "width": 480,
          "style": {
            "text_align": "center",
            "text_color": "#FFFFFF"
          }
        },
        {
          "type": "slider",
          "id": "brightness",
          "min": 0,
          "max": 100,
          "value": 50,
          "x": 50,
          "y": 120,
          "width": 380,
          "onChange": {
            "target_url": "http://192.168.1.100/api/brightness",
            "method": "POST",
            "params": {
              "level": "${self}"
            }
          }
        },
        {
          "type": "label",
          "id": "value_label",
          "text": "50%",
          "x": 0,
          "y": 160,
          "width": 480,
          "style": {
            "text_align": "center"
          }
        }
      ]
    }
  }'

Example 3: QR Code Display

curl -X POST http://192.168.1.18/ui \
  -H "Content-Type: application/json" \
  -H "X-Access-Token: IZYDISPLAY@2026" \
  -d '{
    "template": {
      "widgets": [
        {
          "type": "qrcode",
          "text": "https://massani3.com",
          "size": 200,
          "x": 140,
          "y": 36
        },
        {
          "type": "label",
          "text": "Scan to visit",
          "x": 0,
          "y": 240,
          "width": 480,
          "style": {
            "text_align": "center",
            "text_color": "#94A3B8"
          }
        }
      ]
    }
  }'

Example 4: Dashboard with Multiple Widgets

curl -X POST http://192.168.1.18/ui \
  -H "Content-Type: application/json" \
  -H "X-Access-Token: IZYDISPLAY@2026" \
  -d '{
    "template": {
      "template_id": "dashboard",
      "widgets": [
        {
          "type": "label",
          "text": "Smart Home Dashboard",
          "x": 0,
          "y": 10,
          "width": 480,
          "style": {
            "text_align": "center",
            "text_color": "#38BDF8"
          }
        },
        {
          "type": "obj",
          "x": 10,
          "y": 50,
          "width": 220,
          "height": 200,
          "style": {
            "bg_color": "#1E293B",
            "radius": 10,
            "pad_all": 15
          },
          "widgets": [
            {
              "type": "label",
              "text": "Living Room",
              "x": 0,
              "y": 0,
              "style": {
                "text_color": "#FFFFFF"
              }
            },
            {
              "type": "switch",
              "id": "living_power",
              "checked": true,
              "x": 10,
              "y": 40,
              "onChange": {
                "target_url": "http://192.168.1.100/api/room/living",
                "method": "POST",
                "params": {
                  "power": "${self}"
                }
              }
            },
            {
              "type": "slider",
              "id": "living_bright",
              "min": 0,
              "max": 100,
              "value": 75,
              "x": 10,
              "y": 100,
              "width": 180,
              "onChange": {
                "target_url": "http://192.168.1.100/api/room/living",
                "method": "POST",
                "params": {
                  "brightness": "${self}"
                }
              }
            }
          ]
        },
        {
          "type": "obj",
          "x": 250,
          "y": 50,
          "width": 220,
          "height": 200,
          "style": {
            "bg_color": "#1E293B",
            "radius": 10,
            "pad_all": 15
          },
          "widgets": [
            {
              "type": "label",
              "text": "Bedroom",
              "x": 0,
              "y": 0,
              "style": {
                "text_color": "#FFFFFF"
              }
            },
            {
              "type": "switch",
              "id": "bedroom_power",
              "checked": false,
              "x": 10,
              "y": 40
            }
          ]
        }
      ]
    }
  }'

Example 5: Template Variables

curl -X POST http://192.168.1.18/ui \
  -H "Content-Type: application/json" \
  -H "X-Access-Token: IZYDISPLAY@2026" \
  -d '{
    "template": {
      "widgets": [
        {
          "type": "label",
          "text": "Temperature: ${temp}°C",
          "x": 50,
          "y": 100
        },
        {
          "type": "label",
          "text": "Humidity: ${humidity}%",
          "x": 50,
          "y": 130
        }
      ]
    },
    "data": {
      "temp": "24.5",
      "humidity": "65"
    }
  }'

Serial Commands

Connect via USB serial (115200 baud) for debugging:

Troubleshooting

Device Not Responding

1. Check WiFi connection: WIFI_STATUS via serial
2. Verify IP address in router
3. Ping the device: ping 192.168.1.18
4. Check access token matches

Template Not Loading

1. Validate JSON syntax
2. Check X-Access-Token header
3. View serial output for errors
4. Try with simple template first

Data Updates Fail with "No active template"

Error: 400 {"error":"No active template"}

Cause: Using "id" instead of "template_id" in template

Solution:

// ❌ WRONG - will fail data updates
{
  "template": {
    "id": "my_template",  // Wrong field name!
    "widgets": [...]
  }
}

// ✅ CORRECT - enables data updates
{
  "template": {
    "template_id": "my_template",  // Correct field name
    "widgets": [...]
  }
}

Then data-only updates will work:

{
  "data": {
    "temp": "25.0",
    "humidity": "60"
  }
}

Events Not Firing

1. Ensure target URL is accessible from device
2. Check serial monitor for HTTP errors
3. Verify WiFi connectivity
4. Confirm event URLs are correct

Factory Reset

1. Long-press app name (3 seconds)
2. Click Reset button
3. OR send RESET via serial
4. Device will reboot to setup mode

Security Notes

1. Change default access token in setup
2. Use strong tokens (16+ characters, mix of letters/numbers/symbols)
3. Don't expose device directly to internet
4. Keep device on secure local network

Technical Specifications

Happy Building! 🚀
